Getting Started with pgmonkey: A Comprehensive PostgreSQL Connection Guide

pgmonkey is a powerful Python library designed to simplify and manage PostgreSQL database connections. It supports various connection types, authentication methods (including SSL and certificate-based authentication), and provides a flexible, configuration-driven approach to managing database connections. In addition to its robust Python API, pgmonkey includes a command-line interface (CLI) for easy management of database configurations and connections.

You can find the pgmonkey homepage here https://pgmonkey.net

This tutorial will walk you through the process of installing pgmonkey, creating YAML configuration files, understanding the available authentication methods, using the CLI, and using the library to manage different types of database connections.

Installation

To get started with pgmonkey, you can install it via PyPI by running the following command:

pip install pgmonkey

pgmonkey is available on PyPI https://pypi.org/project/pgmonkey

Alternatively, you can clone the repository from GitHub:

git clone https://github.com/RexBytes/pgmonkey.git
cd pgmonkey
pip install .

https://github.com/RexBytes/pgmonkey

Setting Up YAML Configuration Files

pgmonkey uses YAML files to manage and configure database connections. These configuration files allow you to define various settings, including the type of connection, SSL options, and authentication methods.

Basic Connection Options

Here’s a basic YAML configuration for a normal (synchronous) PostgreSQL connection:

postgresql:
  connection_type: 'normal'  # Options: 'normal', 'pool', 'async', 'async_pool'
  connection_settings:
    connectionName: 'normal_connection'
    description: 'Default PostgreSQL connection setup'
    user: 'your_user'
    password: 'your_password'
    host: 'localhost'
    port: 5432
    dbname: 'your_database'
    sslmode: 'prefer'  # Options: disable, allow, prefer, require, verify-ca, verify-full
    connect_timeout: 10  # Maximum wait for connection, in seconds
    application_name: 'pgmonkey_app'
    keepalives: 1  # Enable TCP keepalives
    keepalives_idle: 60  # Seconds before sending a keepalive probe
    keepalives_interval: 15  # Seconds between keepalive probes
    keepalives_count: 5  # Maximum keepalive probes before closing connection

Connection Pooling Options

If you want to utilize connection pooling, you can extend the configuration like this:

postgresql:
  connection_type: 'pool'
  connection_settings:
    connectionName: 'pool_connection'
    user: 'your_user'
    password: 'your_password'
    host: 'localhost'
    port: 5432
    dbname: 'your_database'
    sslmode: 'prefer'
  pool_settings:
    min_size: 5  # Minimum number of connections in the pool
    max_size: 20  # Maximum number of connections in the pool
    max_idle: 300  # Time (seconds) a connection can remain idle before being closed
    max_lifetime: 3600  # Maximum time (seconds) a connection can be reused

Asynchronous Connection Options

For applications requiring asynchronous database operations, pgmonkey supports async connections:

postgresql:
  connection_type: 'async'
  connection_settings:
    connectionName: 'async_connection'
    user: 'your_user'
    password: 'your_password'
    host: 'localhost'
    port: 5432
    dbname: 'your_database'
    sslmode: 'require'
  async_settings:
    # Uncomment to set specific timeouts or memory settings for async operations
    # idle_in_transaction_session_timeout: '5000'  # Timeout for idle in transaction
    # statement_timeout: '30000'  # Cancel statements exceeding 30 seconds
    # lock_timeout: '10000'  # Timeout for acquiring locks
    # work_mem: '256MB'  # Memory for sort operations and more

For asynchronous connections with pooling:

postgresql:
  connection_type: 'async_pool'
  connection_settings:
    connectionName: 'async_pool_connection'
    user: 'your_user'
    password: 'your_password'
    host: 'localhost'
    port: 5432
    dbname: 'your_database'
    sslmode: 'require'
  async_pool_settings:
    min_size: 5
    max_size: 20
    max_idle: 300
    max_lifetime: 3600

Supported Authentication Methods

pgmonkey supports various PostgreSQL authentication methods, including password-based authentication, SSL/TLS encryption, and certificate-based authentication. Here’s a breakdown of each:

Password-Based Authentication

This is the most common authentication method. The user’s credentials (username and password) are sent to the PostgreSQL server, where they are validated.

Example configuration:

postgresql:
  connection_type: 'normal'
  connection_settings:
    user: 'your_user'
    password: 'your_password'
    host: 'localhost'
    dbname: 'your_database'

SSL/TLS Encryption

SSL/TLS is used to encrypt the connection between your application and the PostgreSQL server, providing security over the network. pgmonkey supports various SSL modes:

• disable: No SSL.
• allow: Attempt SSL connection, fall back to non-SSL if unavailable.
• prefer: Attempt SSL connection, fall back to non-SSL if not supported by the server.
• require: Require SSL connection.
• verify-ca: Require SSL connection and verify the server’s certificate is signed by a trusted CA.
• verify-full: Require SSL connection, verify server’s certificate, and ensure the hostname matches.

Example configuration:

postgresql:
  connection_type: 'normal'
  connection_settings:
    user: 'your_user'
    password: 'your_password'
    host: 'localhost'
    dbname: 'your_database'
    sslmode: 'require'
    sslrootcert: '/path/to/ca.crt'  # Path to the CA certificate

Certificate-Based Authentication

Certificate-based authentication uses SSL client certificates for authentication instead of or in addition to passwords. This method is highly secure and often used in enterprise environments.

Example configuration:

postgresql:
  connection_type: 'normal'
  connection_settings:
    user: 'your_user'
    password: 'your_password'  # Can be optional if using cert authentication only
    host: 'localhost'
    dbname: 'your_database'
    sslmode: 'verify-full'
    sslcert: '/path/to/client.crt'  # Path to the client certificate
    sslkey: '/path/to/client.key'  # Path to the client key
    sslrootcert: '/path/to/ca.crt'  # Path to the root CA certificate

This configuration ensures that:

• The connection is encrypted using SSL/TLS.
• The server’s certificate is verified against the specified CA.
• The client authenticates using its own certificate.

Using the pgmonkey CLI

In addition to the Python API, pgmonkey provides a command-line interface (CLI) that allows you to manage your PostgreSQL configurations and connections directly from the terminal. This section will cover the available CLI commands and how to use them.

Available CLI Commands

Here are the main CLI commands that pgmonkey offers:

• pgmonkey settings: Manage application settings.
• pgmonkey pgconfig: Manage PostgreSQL configurations.

  create: Create a new database configuration file.
  test: Test the database connection using a configuration file.
  generate-code: Generate Python code to connect using a configuration file.

• pgmonkey pgserverconfig: Generate suggested server configuration entries for PostgreSQL.


You can access the help for any command by running:

pgmonkey --help

Creating a PostgreSQL Configuration Template

To create a new PostgreSQL configuration template using the CLI, you can use the pgconfig create command. This command generates a YAML configuration file with a basic template that you can customize.

Example:

pgmonkey pgconfig create --type pg --filepath /path/to/your/config.yaml

In this command:

• --type pg: Specifies that the configuration is for PostgreSQL.
• --filepath /path/to/your/config.yaml: Specifies the path where the new configuration file will be created.

After running this command, you will have a basic YAML configuration file at the specified location. You can then edit this file to customize the connection settings as needed.

Testing a Database Connection

Once you have a configuration file, you can test the connection directly from the command line using the pgconfig test command. This is useful for verifying that your connection settings are correct before integrating them into your application.

Example:

pgmonkey pgconfig test --filepath /path/to/your/config.yaml

This command will attempt to connect to the PostgreSQL database using the settings in the specified YAML file. If the connection is successful, it will print the PostgreSQL version and other relevant information.

Autogen Code From Connection YAML File

Now this one is a game changer… pgmonkey will generate example connection code based on the configuration file. Considering your config file could be a normal connection, a pooled connection, an async connection and an async pooled connection it can be quite time consuming to generate boilerplate code.

I find this amazing, it just quickly boosts your development.

Here, look at this… just wow.

$ pgmonkey pgconfig generate-code --filepath ./pg_async_pool.yaml
postgresql database config file has been detected...
Generated asynchronous pooled connection code using pgmonkey:

# Example Python code for an asynchronous pooled connection using pgmonkey

import asyncio
from pgmonkey import PGConnectionManager

async def main():
    connection_manager = PGConnectionManager()
    config_file_path = './pg_async_pool.yaml'

    # Acquire 6 connections asynchronously from the pool
    connections = [await connection_manager.get_database_connection(config_file_path) for _ in range(6)]

    # Use each connection asynchronously
    for i, connection in enumerate(connections):
        async with connection as conn:
            async with conn.cursor() as cur:
                await cur.execute('SELECT 1;')
                result = await cur.fetchone()
                print(f"Connection {i+1}: {result}")

if __name__ == "__main__":
    asyncio.run(main())

It may not fit your case exactly but it’s an example you can look at and check that the connection works.

More here https://pgmonkey.net/reference.html

Using pgmonkey in Python

After setting up your configuration files and testing them with the CLI, you can use pgmonkey in your Python applications.

Establishing a Connection

Here’s a basic example of how to load a connection configuration and establish a connection using pgmonkey:

import asyncio
from pgmonkey import PGConnectionManager

async def main():
    config_file = '/path/to/your/connection.yaml'
    connection_manager = PGConnectionManager()
    connection = await connection_manager.get_database_connection(config_file)

    try:
        if connection.connection_type == 'async' or connection.connection_type == 'async_pool':
            async with connection as conn:
                async with conn.connection.cursor() as cur:
                    await cur.execute('SELECT version();')
                    print(await cur.fetchone())
        else:
            with connection as conn:
                with conn.connection.cursor() as cur:
                    cur.execute('SELECT version();')
                    print(cur.fetchone())
    finally:
        await connection.disconnect() if asyncio.iscoroutinefunction(connection.disconnect) else connection.disconnect()

if __name__ == "__main__":
    asyncio.run(main())

Running Database Queries

The example above demonstrates how to run a basic query (SELECT version();) to check the PostgreSQL server version. You can replace this query with any SQL command relevant to your use case.

Handling Different Connection Types

pgmonkey dynamically detects the connection type based on the YAML configuration and manages it accordingly.

For example, for a synchronous connection:

if connection.connection_type == 'normal':
    # Handle synchronous connection

For an asynchronous pooled connection:

if connection.connection_type == 'async_pool':
    # Handle asynchronous pooled connection

Example Use Case: Testing Multiple Connections

Let’s create a script that tests multiple database connections using different configurations:

import asyncio
from pgmonkey import PGConnectionManager

# Function to test asynchronous connections
async def test_async_connection(connection, config_name):
    """Test an asynchronous database connection."""
    async with connection as conn:
        async with conn.cursor() as cur:
            await cur.execute('SELECT version();')
            print(f"{config_name}: {await cur.fetchone()}")

# Function to test synchronous connections
def test_sync_connection(connection, config_name):
    """Test a synchronous database connection."""
    with connection as conn:
        with conn.cursor() as cur:
            cur.execute('SELECT version();')
            print(f"{config_name}: {cur.fetchone()}")

async def test_database_connection(config_file, config_name):
    """Determine connection type and test accordingly."""
    connection_manager = PGConnectionManager()

    # Check if the connection is async or sync
    if 'async' in config_file:
        connection = await connection_manager.get_database_connection(config_file)
    else:
        connection = connection_manager.get_database_connection(config_file)  # Sync connection

    try:
        # Handle async connection
        if connection.connection_type in ['async', 'async_pool']:
            await test_async_connection(connection, config_name)
        # Handle sync connection
        else:
            test_sync_connection(connection, config_name)
    finally:
        # Disconnect appropriately based on async/sync
        if asyncio.iscoroutinefunction(connection.disconnect):
            await connection.disconnect()
        else:
            connection.disconnect()

def main():
    base_dir = '/path/to/your/configs/'
    config_files = {
        'pg_async_pool.yaml': base_dir + 'pg_async_pool.yaml',
        'pg_async.yaml': base_dir + 'pg_async.yaml',
        'pg_normal.yaml': base_dir + 'pg_normal.yaml',
        'pg_pool.yaml': base_dir + 'pg_pool.yaml'
    }

    # Run each connection test
    for config_name, config_file in config_files.items():
        print(f"Testing connection with config: {config_name}")
        asyncio.run(test_database_connection(config_file, config_name))

if __name__ == "__main__":
    main()

This script loops through multiple configurations and tests each connection, printing the PostgreSQL version to confirm that the connection works as expected.

Example Use Case: Test Pooling Capability

In the following script we test the pooling capability by creating 5 connections taken from the pool. Make sure your config file specifies enough pool connections.

#!/usr/bin/env python3
import asyncio
from pgmonkey import PGConnectionManager

# Function to test multiple asynchronous connections from the pool
async def test_multiple_async_pool_connections(config_file, num_connections):
    connection_manager = PGConnectionManager()
    connections = []

    # Acquire multiple connections from the async pool
    for _ in range(num_connections):
        connection = await connection_manager.get_database_connection(config_file)  # Async call
        connections.append(connection)

    try:
        # Use each connection
        for idx, connection in enumerate(connections):
            async with connection as conn:
                async with conn.cursor() as cur:
                    await cur.execute('SELECT version();')
                    version = await cur.fetchone()
                    print(f"Async Connection {idx + 1}: {version}")
    finally:
        # Disconnect all connections
        for connection in connections:
            await connection.disconnect()

# Function to test multiple synchronous connections from the pool
def test_multiple_sync_pool_connections(config_file, num_connections):
    connection_manager = PGConnectionManager()
    connections = []

    # Acquire multiple sync connections from the pool
    for _ in range(num_connections):
        connection = connection_manager.get_database_connection(config_file)  # Sync call
        connections.append(connection)

    try:
        # Use each connection
        for idx, connection in enumerate(connections):
            with connection as conn:
                with conn.cursor() as cur:
                    cur.execute('SELECT version();')
                    version = cur.fetchone()
                    print(f"Sync Connection {idx + 1}: {version}")
    finally:
        # Disconnect all connections
        for connection in connections:
            connection.disconnect()

async def main():
    base_dir = '/path/to/your/configs/'
    config_files = {
        'async_pool': base_dir + 'pg_async_pool.yaml',
        'pool': base_dir + 'pg_pool.yaml'
    }

    num_connections = 5  # Number of connections to checkout from the pool

    print("Testing async pool connections:")
    await test_multiple_async_pool_connections(config_files['async_pool'], num_connections)

    print("\nTesting sync pool connections:")
    test_multiple_sync_pool_connections(config_files['pool'], num_connections)

if __name__ == "__main__":
    asyncio.run(main())

You should see output like this,

Testing async pool connections:
Async Connection 1: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)
Async Connection 2: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)
Async Connection 3: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)
Async Connection 4: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)
Async Connection 5: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)

Testing sync pool connections:
Sync Connection 1: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)
Sync Connection 2: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)
Sync Connection 3: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)
Sync Connection 4: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)
Sync Connection 5: ('PostgreSQL 16.2 (Debian 16.2-1.pgdg120+2) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit',)

which confirms pgmonkey is quite good and also helping you with postgresql pooled connections.

Conclusion

pgmonkey is a versatile and powerful tool for managing PostgreSQL connections in Python. With support for various authentication methods, including SSL/TLS and certificate-based authentication, as well as both synchronous and asynchronous connections, it’s designed to fit a wide range of use cases. The built-in CLI makes it easy to manage configurations and test connections directly from the command line, further enhancing its usability.

By following this tutorial, you should now be able to set up and manage your database connections with ease, both through the CLI and within your Python applications.

For more detailed documentation and to contribute, visit the pgmonkey GitHub repository.

Happy coding!

Generating Recommended Server Configuration Entries

In addition to managing client-side database connections, pgmonkey can also assist with server-side configurations. While it doesn’t generate the entire PostgreSQL server configuration file (postgresql.conf), it provides you with the specific entries that are required or recommended based on your connection settings. This is particularly useful for ensuring that your PostgreSQL server is properly configured to work with the settings specified in your pgmonkey configuration file.

How It Works

The pgserverconfig command analyzes your existing pgmonkey configuration file and generates the recommended entries for your postgresql.conf and pg_hba.conf files. These recommendations ensure compatibility with the connection settings you’ve specified, such as SSL requirements, connection pooling, and other critical parameters.

Using the CLI to Generate Server Config Recommendations

To generate server configuration recommendations, you can use the pgserverconfig command from the pgmonkey CLI. This command reads your configuration file and outputs the necessary settings for your PostgreSQL server configuration files.

Example Command

pgmonkey pgserverconfig --filepath /path/to/your/config.yaml

In this command:

• --filepath /path/to/your/config.yaml: Specifies the path to the pgmonkey configuration file you want to analyze.

Output Example

When you run the command, pgmonkey will analyze the configuration file and provide you with entries like the following:

1) Database type detected: PostgreSQL

2) Minimal database server settings needed for this config file:

   a) pg_hba.conf:

TYPE  DATABASE  USER  ADDRESS          METHOD  OPTIONS
hostssl all     all   192.168.0.0/24   md5     clientcert=verify-full

   b) postgresql.conf:

max_connections = 22
ssl = on
ssl_cert_file = 'server.crt'
ssl_key_file = 'server.key'
ssl_ca_file = 'ca.crt'

Please check the following files on your system and ensure that the appropriate settings are applied: pg_hba.conf, postgresql.conf. Ensure that the network ADDRESS matches your network subnet and review all configurations.

What the Output Means

• pg_hba.conf Entries: These entries configure client authentication, ensuring that the server only allows connections that match the specified criteria, such as SSL client certificates and network addresses.
• postgresql.conf Entries: These entries configure server settings like max_connections, SSL settings, and other parameters that are crucial for the server to handle the types of connections you’ve configured in pgmonkey.

Applying the Recommendations

Once you have the recommended entries:

• Open your PostgreSQL server configuration files (pg_hba.conf and postgresql.conf).
• Add or modify the settings as per the recommendations provided by pgmonkey.
• Restart your PostgreSQL server to apply the changes.

Why This Is Important

Ensuring that your server is configured correctly is crucial for the smooth operation of your database connections. Misconfigurations can lead to connection failures, security vulnerabilities, or performance issues. By using pgmonkey to generate these recommendations, you can be confident that your server is set up to work optimally with the connection settings you’ve defined.
